Name : KVM-1700P series
Features :
1. LCD display/Touchpad mouse/104 Keyboard with Digital Zone/E-Switch.
2. Excellent video effects, the best resolution is up to1280*1024 @75HZ.
3. Support DDC2B,can detect the screen model without switching the computer.
4. PS/2 keyboard and mouse are connected to control computer.
5. With drawing installation design, the length can be adjusted to fit the rack space.
6. Humanized design，can be installed and removed by only one person.which improves the efficiency of the administrator.
7. To switch the host computer though the hotkey or OSD menu, which can manage up to 512 computers.
8. Password security protection, only authorized users can view and manage on-line computer.
9. Support a variety of brand industrial computer and the server，such as EVOC,Lenovo,IBM,DELL,HP,SUN,etc.
10. support various operating system: Microsoft, Linux, Unix, etc.
Specification :
1. Model : KVM-1700P Series
2. Computer Connections : Direct 1, Max: 4 Direct 4, Max: 128 Direct 8, Max: 256 Direct 16, Max: 512
3. Cable Port : D-SUB15 (LCD, PS11/USB keyboard, mouse).OSD switch Support.
4. Switch Mode : Hotkey, OSD menu
5. Switch Scan Time : 1-255 second (OSD adjustable)
6. LCD Display : 17" TFT LCD Resolution : 1280*1024 Brightness:300nits Contrast:700:1
7. Keyboard/Mouse : 104 Mechanical mute Keyboard Touchpad
8. Input : AC100-240V 47-63Hz, 35W
9. Cabinet Material : high-strength and Anti-corrosive steel plate
10. Color : Insulated black paint (other colors optional)
11. Dimension : 570.7mm*480mm*44mm ( L x W x H )
12. Weight : 20.6-25.3KG
13. For cabinet : 800-1040mm
14. Storage temperature : -30℃~70℃
15. Working Temperature: -10℃~60℃
16. Humidity : 0%-80%RH
17. Certification : CCC,FCC,CE
Order Information :
1.KVM-1701P 17"TFT/Koyboard/Touchpad/100~240V AC Power
2.KVM-1704P 17"TFT/Koyboard/Touchpad/100~240V AC Power/4 Port Switch
3.KVM-1708P 17"TFT/Koyboard/Touchpad/100~240V AC Power/8 Port Switch
4.KVM-1716P 17"TFT/Koyboard/Touchpad/100~240V AC Power/16 Port Switch |
