Name :KVM-1500H

Features:

·LCD display/Touchpad mouse/104 Keyboard with Digital Zone/E-Switch.
·Excellent video effects, the best resolution is up to1024*768 60HZ.
·Support DDC2B.can detect the screen model without switching the computer.
·Dual interface PS / 2 , USB keyboard and mouse are connected to control computer.
·Withdrawing installation design, the length can be adjusted to fit the rack space.
·Humanized design，can be installed and removed by only one person which improves the efficiency of the administrator.
·To switch the host computer though the hotkey or OSD menu, it can manage up to 512 computers.
·Password security protection, only authorized users can view and manage on-line computer.
·Support a variety of brand industrial computer and the server，such as Siwei, EVOC, Lenovo, IBM, DELL, HP, SUN, etc.
·support various operating systems: Microsoft, Linux, Unix, etc.

Specifications:

Model:	KVM-1501H          KVM-1504H             KVM-1508H               KVM-1516H
Computer Connections:	Direct 1, Max:4  Direct 4, Max:128  Direct 8, Max: 256   Direct 16, Max: 512
Cable port:	D-SUB15 (LCD, PS11/USB keyboard, mouse),OSD switch Support
Switch mode:	Hotkey, OSD menu
Switch Scan Time:	1-255 second (OSD adjustable)
LCD Display:	15"  TFT LCD   Resolution : 1024*768 Brightness:250nits Contrast: 400:1
Keyboard/Mouse:	104 Mechanical mute Keyboard Touchpad
Input:	AC100-240V 47-63Hz, 30W
Cabinet Material:	high-strength and Anti-corrosive steel plate
Color :	Insulated black paint (other colors optional)
Dimension ( L x W x H ):	533.6mmx480mmx44mm
Weight:	19.7-24.2Kg
For cabinet:	800-1040mm
Storage temperature:	-30℃~70℃
work temperature:	-10℃~60℃
Humidity:	0%-80%RH
Certificate:	CCC, FCC, CE

Ordering information:
1：KVM-1501H        15"TFT LCD/Keyboard/Touchpad/100~240V AC Power/
2：KVM-1504H        15"TFT LCD/Keyboard/Touchpad/100~240V AC Power/4 Port Switch
3：KVM-1508H        15"TFT LCD/Keyboard/Touchpad/100~240V AC Power/8 Port Switch
4：KVM-1516H        15"TFT LCD/Keyboard/Touchpad/100~240V AC Power/16 Port Switch
