Name :KVM-1700H
Features:
·LCD display/Touchpad mouse/104 Keyboard with Digital Zone/E-Switch.
·Excellent video effects, the best resolution is up to1280*1024 75HZ.
·Support DDC2B.can detect the screen model without switching the computer.
·Dual interface PS / 2 , USB keyboard and mouse are connected to control computer.
·Withdrawing installation design, the length can be adjusted to fit the rack space.
·Humanized design，can be installed and removed by only one person.which improves the efficiency of the administrator.
·To switch the host computer though the hotkey or OSD menu, which can manage up to 512 computers.
·Password security protection, only authorized users can view and manage on-line computer.
·Support a variety of brand industrial computer and the server，such as Siwei,EVOC,Lenovo,IBM,DELL,HP,SUN,etc.
·Support various operating system: Microsoft, Linux, Unix, etc.
Specifications:
|
Model: |
KVM-1701H KVM-1704H KVM-1708H KVM-1716H |
|
Computer Connections: |
Direct 1, Max: 4 Direct 4, Max: 128 Direct 8, Max: 256 Direct 16, Max: 512 |
|
Cable port: |
D-SUB15 (LCD, PS11 keyboard, mouse),OSD switch Support |
|
Switch mode: |
Hotkey, OSD |
|
Switch Scan Time: |
1-255 second (OSD adjustable) |
|
LCD Display: |
17” TFT LCD Resolution : 1280*1024 Brightness:300nits Contrast: 700:1 |
|
Keyboard/Mouse: |
104 Mechanical mute Keyboard Touchpad |
|
Input: |
AC100-240V 47-63Hz, 35W |
|
Cabinet Material: |
high-strength and Anti-corrosive steel plate |
|
Color : |
Insulated black paint (other colors optional) |
|
Dimension (L x W x H): |
609.2mm*480mm*44mm |
|
Weight: |
20.6- 25.3KG |
|
For cabinet: |
800-1040mm |
|
Storage temperature: |
-30℃~70℃ |
|
work temperature: |
-10℃~60℃ |
|
Humidity: |
0%-80%RH |
|
Certificate: |
CCC, FCC, CE |
Ordering information:
1：KVM-1701H 17"TFT LCD/Keyboard/Touchpad/100~240V AC Power
2：KVM-1704H 17"TFT LCD/Keyboard/Touchpad/100~240V AC Power/4 Port Switch
3：KVM-1708H 17"TFT LCD/Keyboard/Touchpad/100~240V AC Power/8 Port Switch
4：KVM-1716H 17"TFT LCD/Keyboard/Touchpad/100~240V AC Power/16 Port Switch |
